KK-03 compact electric actuator delivers 30Nm torque with AC230V/DC24V/DC12V options, 90° rotation in 5S/1S, IP67 protection, ideal for small-diameter ball valves in industrial automation.
Specifications
| Model | KK-03 | ||
| Power supply (V) | DC24V | AC110V | AC220V |
| Output torque | 24NM | 24NM | 24NM |
| Action times (S) | 12S | 12S | 12S |
| Scope of rotary angle (°) | 0-90° | 0-90° | 0-90° |
| Motor power (W) | 4W | 6.5W | 5W |
| Rated current (A) | 1A | 0.2A | 0.1A |
| Machine weight (kg) | 1.5Kg | 1.5Kg | 1.5Kg |
| Insulation Resistance (MΩ) | DC24V: 100MΩ/250VDC AC110V/220V: 100MQVDC | ||
| Voltage Resistance Rating | DC24V: 500VAC: AC110V/220V: 1500VAC (1 Minute) | ||
| Protection Level | IP67 | ||
| Installation Position | Rotary range: 360°Any position | ||
| Electrical connection | Each one G1/2 water-proof cable connectors, Electric power lines, Signal lines | ||
| Environment temperature | -20℃~+60℃ | ||
| Control circuit options | Standard type: Limit position switch A type: with mid-position switch |
||
| Optional function | Dehumidification heater | ||
