KK-05 standard electric actuator provides 50Nm torque with DC24V/AC110V/AC220V/AC380V options. IP67 protection and 360° mounting flexibility suit ball and butterfly valve automation across industries.
Specifications
| Model | KK-05 | |||
| Power supply (V) | DC24V | AC110V | AC220V | AC380V |
| Output torque | 50NM | 50NM | 50NM | 50NM |
| Action times (S) | 10S | 20S | 20S | 20S |
| Scope of rotary angle (°) | 0-90° | 0-90° | 0-90° | 0-90° |
| Motor power (W) | 20W | 10W | 15W | 10W |
| Rated current (A) | 2.0A | 0.48A | 0.26A | 0.1A |
| Machine weight (kg) | 2.2Kg | 2.2Kg | 2.2Kg | 2.2Kg |
| Insulation Resistance (MΩ) | DC24V: 100MΩ/250VDC AC110V/380V: 100MΩ/500VDC | |||
| Voltage Resistance Rating | DC24V: 500VAC: AC110V/220V: 1500VAC: AC380V: 1800VAC. (1 Minute) | |||
| Protection Level | IP67 | |||
| Installation Position | Rotary range: 360°Any position | |||
| Electrical connection | Each one G1/2 water-proof cable connectors, Electric power lines, Signal lines | |||
| Environment temerature | -20℃~+60℃ | |||
| Control circuit options | Standard type: Limit position switch A type: with mid-position switch B type: with potentiometer C type: with potentiometer and mid-position switch. D type: with 4-20MA (Intelligent type). |
|||
| Optional function | Over torque protectors, Dehumidity heater | |||
