KK-EX-10 explosion-proof electric actuator delivers 100Nm torque with ATEX/IECEx certification for Zone 1 and Zone 2. IP67 protection ensures reliable valve automation in oil, gas and chemical industries.
Specifications
| Model | KK-EX-10 | |||
| Power supply (V) | DC24V | AC110V | AC220V | AC380V |
| Output torque | 100NM | 100NM | 100NM | 100NM |
| Action times (S) | 30S | 30S | 30S | 30S |
| Scope of rotary angle (°) | 0-90° | 0-90° | 0-90° | 0-90° |
| Motor power (W) | 25W | 25W | 25W | 25W |
| Rated current (A) | 2.03A | 0.57A | 0.35A | 0.10A |
| Machine weight (kg) | 7Kg | 7Kg | 7Kg | 7Kg |
| Motor protection | Built-in thermal protection | |||
| Insulation Resistance (MΩ) | DC24V:100MQ/250VDC AC110V/220V 380V:100MΩ/500VDC | |||
| Voltage Resistance Rating | DC24V: 500VAC; AC110V/220V: 1500VAC; AC380V: 1800VAC. (1Minute) | |||
| Manual operation | It comes with stainless steel handles | |||
| Protection Level | IP67 | |||
| Installation Position | Rotary range: 360°Any position | |||
| Environment temperature | -20℃~+60℃ | |||
| Electrical connection | Each one G1/2 water-proof cable connectors, Electric power lines, Signal lines | |||
| Control circuit options | Standard type: Limit position switch A type: with mid-position switch B type: with potentiometer D type: with 4-20MA (Intelligent type) |
|||
| Optional function | Over torque protectors, Dehumidity heater | |||
