KK-10 medium-torque electric actuator delivers 100Nm output with DC24V/AC110V/AC220V/AC380V power. IP67 housing and 15-30S action time suit medium-size ball and butterfly valve control.
Specifications
| Model | KK-10 | |||
| Power supply (V) | DC24V | AC110V | AC220V | AC380V |
| Output torque | 100NM | 100NM | 100NM | 100NM |
| Action times (S) | 15S | 30S | 30S | 30S |
| Scope of rotary angle (°) | 0-90° | 0-90° | 0-90° | 0-90° |
| Motor power (W) | 25W | 25W | 25W | 25W |
| Rated current (A) | 4.0A | 0.57A | 0.28A | 0.10A |
| Machine weight (kg) | 4.0Kg | 4.0Kg | 4.0Kg | 4.0Kg |
| Insulation Resistance (MΩ) | DC24V: 100MΩ/250VDC AC110V/220V 380V: 100MΩ/500VDC | |||
| Voltage Resistance Rating | DC24V: 500VAC; AC110V/220V: 1500VAC; AC380V: 1800VAC (1 Minute) | |||
| Protection Level | IP67 | |||
| Installation Position | Rotary range: 360° Any position | |||
| Electrical connection | Each one G1/2 water-proof cable connectors, Electric power lines, Signal lines | |||
| Environment temperature | -20℃~+60℃ | |||
| Control circuit options | Standard type: Limit position switch A type: with mid-position switch B type: with potentiometer D type: with 4-20MA (Intelligent type) |
|||
| Optional function | Over torque protectors, dehumidifier heater | |||
