KK-EX-20/40/60/80 high-torque explosion-proof electric actuator series provides 200Nm to 800Nm with ATEX certification. IP67 protection and thermal protection ensure safe operation in hazardous petrochemical environments.
Specifications
| Model | KK-EX-20 | KK-EX-40 | KK-EX-60 | KK-EX-80 |
| Output torque | 200NM | 400NM | 600NM | 800NM |
| Action times(S) | 15S/30S/45S | 30S/45S | 30s/45s | 60S |
| Scope of rotary angle(°) | 0-90° | 0-90° | 0-90° | 0-90° |
| Motor power(w) | 40W/30W | 90W/60W | 100w | 100W |
| Rated current(A) | 0.37A/0.25A | 0.69A/0.51A | 0.69A | 0.85A |
| Machine weight(kg) | 11Kg | 11Kg | 11.3Kg | 11.50Kg |
| Power supply(V) | DC24V AC110V AC220V±10% 50HZ/60HZ AC380V | |||
| Motor protection | Built-in thermal protection | |||
| Insulation Resistance(MΩ) | 100MΩ/500VDC | |||
| Voltage Resistance Rating | 1500VAC(1Minute) | |||
| Manual operation | It comes with stainless steel handles | |||
| Protection Level | IP67 | |||
| Installation Position | Rotary range: 360°Any position | |||
| Electrical connection | Each one with G1/2 water-proof cable connectors, Electric power lines, Signal lines | |||
| Environment temperature | -20℃~+60℃ | |||
| Control circuit options | Standard type: Limit position switch. A type: with mid-position switch. B type: with potentiometer. D type: with 4-20MA (Intelligent type). |
|||
| Optional function | Over torque protectors, Dehumidity heater | |||
