KINKO YT-1000R rotary valve positioner provides precise 0-90° control with 4-20mA input and NEPSI explosion-proof rating, ideal for butterfly and ball valve automation in chemical and petrochemical plants.
Product Overview
There is no resonance phenomenon within the range of 5-200Hz. Positive and negative effects, as well as single and double effects, can be easily converted. For the vibration generated by small actuators, it can be solved by adding a throttle hole to the locator. Low air consumption and good economy. It is possible to achieve split range control within 1/2 range without replacing parts.
Specifications
| Model | YT-1000R | |
| Item Type | Single | Double |
| Input Signal | 4~20mA DC | |
| Impedance | 250±15 Ohm | |
| Supply Pressure | 0.14~0.7Mpa (1.4~7bar) | |
| Stroke | 0~90° | |
| Air Connection | NPT1/4 (conventional)G1/4, PT1/4 | |
| Gauge Connection | PT(NPT)1/8 | |
| Conduit | NPT 1/2, G1/2, M20×1.5 | |
| Explosion Proof | NEPSI ExiallCT6Ga, ExdbllICT6Gb, ExtbllCT80℃Db | |
| Enclosure | IP66 | |
| Ambient Temp. | Room temperature type is -20~60℃ | |
| Linearity | ±1.0%FS | ±2.0%FS |
| Hysteresis | ±1.0%FS | |
| Sensitivity | ±0.2%FS | ±0.5%FS |
| Repeatability | ±0.5%FS | |
| Air Consumption | 2.5LPM (Sup=0.14Mpa) | |
| Flow Capacity | 80LPM (Sup=0.14Mpa) | |
| Material | Aluminum Diecasting | |
| Weight | 2.8kg (6.2lb) | |
