KINKO YT-1000L linear valve positioner accepts 4-20mA DC signal with 10-150mm stroke and 0.14-0.7MPa supply, offering low air consumption and NEPSI explosion-proof certification for process control valves.
Product Overview
No resonance phenomenon within the range of 5-200Hz.
Positive and negative effects, and easy conversion between single and double effects
For the vibration generated by small actuators, it can be solved by adding a throttle hole to the locator.
Low air consumption, good economy
Can achieve split range control within 1/2 range without replacing parts.
Specifications
| Item Type | YT-1000L | |
| Single | Double | |
| Input Signal | 4~20mA DC | |
| Impedance | 250±15 Ohm | |
| Supply Pressure | 0.14~0.7Mpa (1.4~7bar) | |
| Stroke | 10~150mm | |
| Air Connection | NPT1/4 (conventional) G1/4, PT1/4 | |
| Gauge Connection | PT 1/8 | |
| Conduit | NPT1/2(conventional), G1/2, M20×1.5 | |
| Explosion Proof | NEPSI ExiallCT6Ga, ExdblICT6Gb, ExtbllCT80℃Db | |
| Enclosure | IP66 | |
| Ambient Temp. | Room temperature type is -20~60℃ | |
| Linearity | ±1.0%FS | ±2.0%FS |
| Hysteresis | ±1.0%FS | |
| Sensitivity | ±0.2%FS | ±0.5%FS |
| Repeatability | ±0.5%FS | |
| Air Consumption | 2.5LPM (Sup=0.14Mpa) | |
| Flow Capacity | 80LPM (Sup=0.14Mpa) | |
| Material | Aluminum Diecasting | |
| Weight | 2.7kg (6.1b) | |
