KINKO mounting bracket selection guide offers carbon steel or 304 stainless steel brackets with ISO 5211 compatibility, ensuring easy actuator-to-valve mounting for various quarter-turn and linear applications.
Specifications
| Model | Picture | Material | Size | Application |
| MBP-001 |  |
Carbon Steel or Stainless Stee |
W:30 L:80 H:20 |
DK2XX DS5XX DS6XX |
| MBP-002 |  |
Carbon Steel or Stainless Steel |
W:30 L:80 H:30 |
DK2XX DS5XX DS6XX |
| MBP-003 |  |
Carbon Steel or Stainless Steel |
W:30 L:80 H:45 |
DK2XX DS5XX DS6XX |
| MBP-004 |  |
Carbon Steel or Stainless Steel |
W:30 L:130 H:40 |
DK2XX DS5XX DS6XX |
| MBP-005 |  |
Carbon Steel or Stainless Steel |
W:30 L:80 H:30-40 |
DK2XX DS5XX DS6XX |
| MBP-006 |  |
Carbon Steel or Stainless Steel |
W:30 L:130 H:40 |
DK2XX DS5XX DS6XX |
| MBP-007 |  |
Carbon Steel or Stainless Steel |
W:30 L:80-130 H:30-40 |
DK2XX DS5XX DS6XX |
| MBP-008 |  |
Carbon Steel or Stainless Steel |
W:30 L:80 H:30-40 |
DK2XX DS5XX DS6XX |
| MBP-009 |  |
Carbon Steel or Stainless Stee |
W:30 L:50 H:30 |
DK2XX DS5XX DS6XX |
| MBP-010 |  |
Carbon Steel or Stainless Steel |
W:30 L:80 H:50 |
DS3XX |
| MBP-011 |  |
Carbon Steel or Stainless Steel |
W:30 L:80-130 H:40-50 |
DS3XX |
| MBP-012 |  |
Carbon Steel or Stainless Steel |
W:30 L:80 H:35-50 |
DK2XX DS5XX DS6XX DS3XX DS4XX DS4XX-VPX Dk310 |
| MBP-013 |  |
Carbon Steel or Stainless Steel |
W:30 L:130 H:35-55 |
DK2XX DS5XX DS6XX DS4XX DS4XX-VPX Dk310 |
| MBP-014 |  |
Carbon Steel or Stainless Steel |
W:30 L:80-130 H:30-40 |
DK1XX |
| MBP-230 |  |
Plastic or Aluminum |
W:30 L:80 H:20-50 |
DK230 |
