KINKO APL510 series valve limit switch box features die-cast aluminum housing with IP66 protection, offering mechanical SPDT×2 or proximity switch options for reliable valve position feedback in industrial automation.
Product Overview
Specifications
| Item/Model | APL-510 Series Valve Limit Switch Box | |
| Housing Material | Die-Casting Aluminum or 316 Stainless Steel Optional | |
| Housing Paintcoat | Material: Polyester Powder Coating | |
| Color: Customizable Black, Blue, Green, Yellow, Red, Silver, etc. | ||
| Switch Specification | Mechanical Switch (SPDT)×2 |
5A 250VAC: Ordinary |
| 16A 125VAC/250VAC: Omron, Honeywell, etc. | ||
| 0.6A 125VDC: Ordinary, Omron, Honeywell, etc. | ||
| 10A 30VDC: Ordinary, Omron, Honeywell, etc. | ||
| Proximity Switch ×2 |
≤150mA 24VDC: Ordinary | |
| ≤150mA 30VDC: Pepperl+Fuchs NBB3, etc. | ||
| ≤150mA 8VDC: Intrinsically Safe Ordinary, Intrinsically Safe Pepperl+Fuchs NJ2, etc. |
||
| Terminal Blocks | 8 points | |
| Ambient Temperature | Common type -20℃ to+80℃, customizable low-temperature type. | |
| Weather Proof Grade | IP66 | |
| Explosion Proof Grade | EXDIICT6, EXiaCT4, EXialICT6 | |
| Mounting Bracket | Optional Material: Carbon Steel or 304 Stainless Steel Optional | |
| Optional Model: Refer to Mounting Bracket Selection Table | ||
| Fastener | Carbon Steel or 304 Stainless Steel Optional | |
| Indicator Lid | Flat Lid,Dome Lid | |
| Position Indication Color | Close: Red, Open: Yellow | |
| Close: Red, Open: Green | ||
| Cable Entry | Qty: 2 | |
| Specifications: G34, NPT 1/2, NPT 3/4, M20 | ||
| Position Transmitter | 4 to 20mA, with 24VDC Supply | |
| Single Net Weight | Die-Casting Aluminum: 1.30 Kgs, 316 Stainless Steel: 3.40 Kgs | |
| Packing Specifications | 1Pcs/Box, 16 Pcs/Carton | |
