KINKO TPX410 series valve limit switch box offers compact die-cast aluminum housing with IP66 rating, supporting mechanical or proximity switches for space-constrained valve position indication applications.
Product Overview
Specifications
| Item/Model | TPX410 Series Valve Limit Switch Box | |
| Housing Material | Die-Casting Aluminum | |
| Housing Paintcoat | Material: Polyester Powder Coating | |
| Color: Customizable Black, Blue, Green, Yellow, Red, Silver, etc. | ||
| Switch Specification | Mechanical Switch (SPDT)×2 |
16A 125VAC/250VAC: Honeywell |
| 0.6A 125VDC: Honeywell | ||
| 10A 30VDC: Honeywell | ||
| Terminal Blocks | 8 points | |
| Ambient Temperature | Common type -20℃ to+80℃, Customizable low-temperature type. | |
| Weather Proof Grade | IP66 | |
| Explosion Proof Grade | EXDIIBT6 | |
| Mounting Bracket | Optional Material: Carbon Steel or 304 Stainless Steel Optional | |
| Optional Model: Refer to Mounting Bracket Selection Table | ||
| Fastener | Carbon Steel or 304 Stainless Steel Optional | |
| Indicator Lid | Flat Lid | |
| Position Indication Color | Close: Red, Open: Yellow | |
| Close: Red, Open: Green | ||
| Cable Entry | Qty:2 | |
| Specifications: NPT 12, M20 | ||
| Position Transmitter | 4 to 20mA,with 24VDC Supply | |
| Single Net Weight | 1.60 Kgs | |
| Packing Specifications | 1 Pcs/Box, 12 Pcs/Carton | |
Application & Case
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Aenean euismod bibendum laoreet. Proin gravida dolor sit amet lacus accumsan et viverra justo commodo. Proin sodales pulvinar sic tempor. Sociis natoque penatibus et magnis dis parturient montes, nascetur ridiculus mus. Nam fermentum, nulla luctus pharetra vulputate, felis tellus mollis orci, sed rhoncus pronin sapien nunc accuan eget.
