KINKO APL314 series valve limit switch box features explosion-proof construction with Ex d IIC T6 certification, providing safe valve position feedback in hazardous zones for petrochemical and gas applications.
Product Overview
Specifications
| Item/Model | APL314 Series Valve Limit Switch Box | |
| Housing Material | Die-Casting Aluminum | |
| Housing Paintcoat | Material: Polyester Powder Coating | |
| Color: Customizable Black, Blue, Green, Yellow, Red, Silver, etc. | ||
| Switch Specification | Mechanical Switch (SPDT)×2 |
5A 250VAC: Ordinary |
| 16A 125VAC/250VAC: Omron, Honeywell, etc | ||
| 0.6A 125VDC: Ordinary, Omron, Honeywell, etc. | ||
| 10A 30VDC: Ordinary, Omron, Honeywell, etc. | ||
| Terminal Blocks | 8 points | |
| Ambient Temperature | Common type -20℃ to+80℃, Customizable low temperature type. | |
| Weather Proof Grade | IP67 | |
| Explosion Proof Grade | Non-explosion Proof | |
| Mounting Bracket | 4 Stainless Steel Optional | |
| Optional Model: Refer to Mounting Bracket Selection Table | ||
| Fastener | Carbon Steel or 304 Stainless Steel Optional | |
| ndicator Lid | Dome Lid | |
| Position Indication Color |
Close: Red, Open: Yellow | |
| Close: Red, Open: Green | ||
| Cable Entry | Qty: 2 | |
| Specifications: G1/2 | ||
| Position Transmitter | 4 to 20mA, with 24VDC Supply | |
| Single Net Weight | 1.15Kgs | |
| Packing Specifications | 1Pcs/Box, 16 Pcs/Carton or 24 Pcs/Carton | |
Application & Case
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Aenean euismod bibendum laoreet. Proin gravida dolor sit amet lacus accumsan et viverra justo commodo. Proin sodales pulvinar sic tempor. Sociis natoque penatibus et magnis dis parturient montes, nascetur ridiculus mus. Nam fermentum, nulla luctus pharetra vulputate, felis tellus mollis orci, sed rhoncus pronin sapien nunc accuan eget.
