KINKO APL210 series valve limit switch box offers standard die-cast aluminum housing with IP67 protection, featuring mechanical switches for reliable valve position indication in general industrial automation.
Product Overview
Specifications
| Item/Model | APL210 Series Valve Limit Switch Box | |
| Housing Material | Die-Casting Aluminum | |
| Housing Paintcoat | Material: Polyester Powder Coating | |
| Color: Customizable Black, Blue, Green, Yellow, Red, Silver, etc. | ||
| Switch Specification | Mechanical Switch (SPDT)×2 |
5A 250VAC:Ordinary |
| 16A 125VAC/250VAC: Omron, Honeywell, etc. | ||
| 0.6A 125VDC: Ordinary, Omron, Honeywell, etc. | ||
| 10A 30VDC: Ordinary, Omron, Honeywell, etc. | ||
| Proximity Switch ×2 |
≤150mA 24VDC:Ordinary | |
| ≤150mA 30VDC:Pepperl+FuchsNBB3,etc. | ||
| ≤150mA 8VDC: Intrinsically Safe Ordinary, Intrinsically Safe Pepperl+fuchsNJ2, etc. |
||
| Terminal Blocks | 8 points | |
| Ambient Temperature | Common type-20℃ to+80℃, customizable low-temperature type. | |
| Weather Proof Grade | IP67 | |
| Explosion Proof Grade | Non-explosion Proof, EXiallCT4, EXialICT6 | |
| Mounting Bracket | Optional Material: Carbon Steel or 304 Stainless Steel Optional | |
| Optional Model: Refer to Mounting Bracket Selection Table | ||
| Fastener | Carbon Steel or 304 Stainless Steel Optional | |
| Indicator Lid | Flat Lid, Dome Lid | |
| Position Indication Color | Close: Red, Open: Yellow | |
| Close: Red, Open: Green | ||
| Cable Entry | Qty: 2 | |
| Specifications: G1/2, NPT 1/2, M20 | ||
| Position Transmitter | 4 to 20mA, with 24VDC Supply | |
| Single Net Weight | 0.570 Kgs | |
| Packing Specifications | 1Pcs/Box, 50 Pcs/Carton | |
