Mechanical switch (SPDT)*2 (SPDT)*4 (DPDT)*2
KINKO APL500-SS limit switch box offers durable stainless steel construction and reliable position feedback, suitable for harsh environments with multiple cable entry options.
| Item/Model | APL500-SS Series Limit Switch Box | |
| Material | Standard: Aluminum alloy | |
| Option:S tainless Steel 316 | ||
| Enclosure | Standard: Weather-proof enclosure IP66 | |
| Travel angle | 0~90° | |
| Switches | Mechanical switch (SPDT)*2 (SPDT)*4 (DPDT)*2 |
5A 250VAC:Ordinary |
| 16A 125VAC/250VAC: Omron, Honeywell, etc | ||
| 10A 30VDC: Ordinary, Omron, Honeywell, etc | ||
| Proximity switch*2 | ≤100mA 12-24VDC: Ordinary | |
| ≤100mA 5-60VDC: P&F NBB3, etc | ||
| 8.2VDC Intrinsically safe: Ordinary Intrinsically safe P&F NJ2,etc |
||
| Ambient temperature | Standard:-20~60℃ | |
| Option:-40~60℃,-60~60℃ | ||
| Cable entry | 2X NPT1/2, NPT3/4, M20, G3/4 | |
| Terminal strips | Standard: 8 points | |
| Option: 12 points | ||
| Shaft | Standard: Stainless Steel 316 | |
| Fasten screw | Standard: Stainless Steel 316 | |
| Indicator lid | Dome lid | |
| Fat lid | ||
| Indicator | 2-way: yellow (open) / red (close) | |
| 2-way: green (open) / red (close) | ||
| Weight | Stainless Steel 316:3.4 kg (without bracket) | |
| Coating | Black, Red, Yellow, Blue, Silver, etc | |
| Packaging specification | 1 pc/box, 4 pcs/carton | |
