KINKO APL310 series valve limit switch box provides clear visual position indication with die-cast aluminum housing and IP67 protection, featuring SPDT mechanical switches for quarter-turn valve feedback in process industries.
Product Overview
Specifications
| Item/Model | APL310 Series Valve Limit Switch Box | |
| Housing Material | Die-Casting Aluminum | |
| Housing Paintcoat | Material: Polyester Powder Coating | |
| Color: Customizable Black, Blue, Green, Yellow, Red, Silver, etc. | ||
| Switch Specification | Mechanical Switch (SPDT)×2 |
5A 250VAC:Ordinary |
| 16A 125VAC I250VAC: Omron, Honeywell, etc | ||
| 0.6A 125VDC: Ordinary, Omron, Honeywell, etc. | ||
| 10A 30VDC: Ordinary, Omron, Honeywell, etc. | ||
| Terminal Blocks | 8 points | |
| Ambient Temperature | Common type -20℃ to+80℃, customizable low-temperature type. | |
| Weather Proof Grade | IP67 | |
| Explosion Proof Grade | Non-explosion Proof | |
| Mounting Bracket | Optional Material: Carbon Steel or 304 Stainless Steel Optional | |
| Optional Model: Refer to Mounting Bracket Selection Table | ||
| Fastener | Carbon Steel or 304 Stainless Steel Optional | |
| Indicator Lid | Flat Lid, Dome Lid | |
| Position Indication Color |
Close: Red, Open: Yellow | |
| Close: Red, Open: Green | ||
| Cable Entry | Qty:2 | |
| Specifications: G1/2 | ||
| Position Transmitter | 4 to 20mA, with 24VDC Supply | |
| Single Net Weight | 1.10 Kgs | |
| Packing Specifications | 1Pcs/Box,16 Pcs/Carton or 24 Pcs/Carton | |
