KINKO APL300-B-SS limit switch box features stainless steel housing and IP67 protection, providing reliable valve position feedback with mechanical switches for industrial automation.
Product Overview
Specifications
| Item/Model | APL300-B-SS Series Limit Switch Box | |
| Material | Standard: Stainless Steel 316 | |
| Enclosure | Standard: Weather-proof enclosure IP66/IP68 | |
| Travel angle | 0~90° | |
| Switches | Mechanical switch (SPDT)*2 (DPDT)*2 |
5A 250VAC: Ordinay |
| 16A 125VAC/250VAC: Omron, Honeywell, etc | ||
| 10A 30VDC: Ordinary, Omron, Honeywell, etc | ||
| Proximity switch*2 | ≤100mA 12-24VDC: Ordinary | |
| ≤100mA 5-60VDC: P&F NBB3, etc | ||
| 8.2VDC Intrinsically safe: Ordinary Intrinsically safe P&F NJ2, etc |
||
| Ambient temperature | Standard: -20~60℃ | |
| Option: -40~60℃, -60~60℃ | ||
| Cable entry | 2(or 3) XNPT1/2", NPT3/4", G1/2", M20 | |
| Terminal strips | Standard: 8 points | |
| Option: 12 points | ||
| Shaft | Standard: Stainless Steel 316 | |
| Fasten screw | Standard: Stainless Steel 316 | |
| Indicator lid | Fat lid | |
| 2-way: green (open) / red (close) | ||
| Weight | 1.25 kg (without bracket) | |
| Coating | Black, Red, Yellow, Blue, Silver, etc | |
| Packaging specification | 1 pc/box, 8 pcs/carton | |
