KINKO APL230 series valve limit switch box features polyamide bottom with polycarbonate top cover and IP67 protection. Economic compact design with mechanical SPDT×2 switches provides reliable open/close indication for quarter-turn valves.
Product Overview
Specifications
| Item/Model | APL230 Series Valve Limit Switch boxes | |
| Housing Material | Polyamide Bottom with Polycarbonate Top Cover | |
| Housing Color | Black Bottom with Transparent Cover | |
| Switch Specification | Mechanical Switch (SPDT)×2 |
5A 250VAC:Ordinary |
| 16A 125VAC/250VAC: Omron, Honeywell, etc | ||
| 0.6A 125VDC: Ordinary, Omron, Honeywell, etc. | ||
| 10A 30VDC: Ordinary, Omron, Honeywell, etc. | ||
| Terminal Blocks | 8 points | |
| Ambient Temperature | Common type -20℃ to+80℃, Customizable low-temperature type. | |
| Weather Proof Grade | IP67 | |
| Explosion Proof Grade | Non-explosion Proof | |
| Mounting Bracket | Optional Material: Polyamides or Aluminum | |
| Optional Model: Refer to Mounting Bracket Selection Table | ||
| Fastener | Optional: Carbon Steel, 304 Stainless Steel | |
| Indicator Lid | Flat Lid | |
| Position Indication Color |
Close: Red, Open: Yellow | |
| Close: Red, Open: Green | ||
| Cable Entry | Qty: 1 or 2 | |
| Specifications: NPT 1/2 | ||
| Position Transmitter | 4 to 20mA, with 24VDC Supply | |
| Single Net Weight | 0.25 Kgs | |
| Packing Specifications | 1Pcs/Box, 40 Pcs/Carton | |
