• Pilot-Operatedstructure
• Made of Stainless Steel 316
• Standard solenoid valves are supplied as double units
• Universal for both 5/2 way and 3/2 way valve
• NAMUR mounting standard
• No need to add oil for lubrication
Product Overview
Certificate and approvals
• SIL3
• CE
• CCC (Ex db IIC T6 Gb, Ex tb IIIC T80℃ Db)
• EAC (1Ex db h IIC T6 Gb X, Ex h tb IIIC T80℃ DbX)
Specifications
| Model | KK800-XC-SS Series |
| Material of body | Stainless Steel 316 |
| Enclosure | Weatherproof enclosure IP66 |
| Fluid | Air (to be filtered by 40 μm filter element) |
| Valve type | Universal for both 5/2 way and 3/2 way |
| Operating pressure | 1~8 bar |
| Temperature | -20~60℃, -40~60℃ |
| Orifice size CV | 25mm² CV=1.4 |
| Voltage & Consumed power | 3.5W 110/220VAC |
| 3.0W 24DVC | |
| Port size | G1/4", NPT1/4" |
| Cable Entry | M20*1.5, NPT1/2",G1/2" |
| Product life | More than 3.5million times (under normal working conditions) |
Note 1: Once lubricated air is used, continue with the same medium to optimise valve lifespan.
Lubricants like ISO VG32 or equivalent are recommended.
Note 2: Equivalent orifice S and Cv are all calculated from the flow rate data.
